Fungsi dan Penggunaan
Kontaktor arus bolak-balik CJX1 seri terutama digunakan untuk sirkuit daya dengan frekuensi 50Hz arus bolak-balik, tegangan isolasi nominal 660V atau 1000V, dan tegangan kerja nominal 380V di bawah kategori penggunaan AC-3 dengan arus kerja nominal 9A-475A. Digunakan untuk menghubungkan dan memutuskan sirkuit secara jarak jauh, serta cocok untuk mengontrol start, stop, dan perubahan arah motor listrik arus bolak-balik.
Parameter Detail
| Kategori Parameter | Item Parameter | Nilai Parameter |
|---|
| Jenis Kontaktor | | CJX1-9,12;CJX1-9Z,12Z |
| | CJX1-16,22;CJX1-16Z,22Z |
| | CJX1-32 |
| | CJX1-45,63 |
| | CJX1-75,85 |
| | CJX1-110,140 |
| | CJX1-170,205 |
| | CJX1-250,300 |
| | CJX1-400,475 |
| Keterangan Gambar | | |
| Tingkat Kerja Terkait | | 9-12 |
| | 16-22 |
| | 32 |
| | 45-63 |
| | 75-85 |
| | 110-140 |
| | 170-205 |
| | 250-300 |
| | 400-475 |
| Kepaduan Arus Bebas Panas yang Ditetapkan Ith(A) | | 20 |
| | 31.5 |
| | 40 |
| | 63 |
| | 80 |
| | 100 |
| | 160 |
| | 210 |
| | 300 |
| | 400 |
| | 475 |
| Tegangan Isolasi Terkait Ue(V) | | 660 |
| | 1000 |
| Tegangan Impuls Tahan Terkait Uimp(kV) | | 6 |
| Kekuatan Arus Pendek Terkait(IkA) | | 10 |
| | 50 |
| Hambatan Kutub Z(Ω) | | ≤5.0×10³ |
| Kemampuan Pemutusan Terkait | | Kemampuan Koneksinya:10×le(AC-3) atau 12×le(AC-4) |
| Kemampuan Pemutusan Terkait | | Kemampuan Pemutusan:8×le(AC-3) atau 10×le(AC-4) |
| Kekuatan Kontrol Terkait(kW) | AC-3 | 220/380V |
| | 9 |
| | 12 |
| | 16 |
| | 22 |
| | 32 |
| | 45 |
| | 63 |
| | 75 |
| | 75 |
| | 110 |
| | 140 |
| | 170 |
| | 205 |
| | 250 |
| | 300 |
| | 400 |
| | 475 |
| AC-4 | 380V |
| | 7.2 |
| | 9.5 |
| | 13.5 |
| | 13.5 |
| | 18 |
| | 63 |
| | 63 |
| | 75 |
| | 110 |
| | 140 |
| | 160 |
| | 205 |
| | 205 |
| | 205 |
| | 300 |
| | 400 |
| | 400 |
| AC-3 | 220V |
| | 2.4 |
| | 3.3 |
| | 4 |
| | 6.1 |
| | 15 |
| | 22 |
| | 26 |
| | 37 |
| | 73 |
| | 55 |
| | 75 |
| | 110 |
| | 132 |
| | 160 |
| | 200 |
| | 250 |
| AC-4 | 380V |
| | 4 |
| | 5.5 |
| | 7.5 |
| | 11 |
| | 15 |
| | 22 |
| | 30 |
| | 37 |
| | 45 |
| | 55 |
| | 75 |
| | 90 |
| | 100 |
| | 156 |
| | 235 |
| | 375 |
| AC-3 | 660V |
| | 5.5 |
| | 7.5 |
| | 11 |
| | 11 |
| | 23 |
| | 39 |
| | 55 |
| | 67 |
| | 67 |
| | 100 |
| | 100 |
| | 156 |
| | 235 |
| | 375 |
| AC-4 | 660V |
| | 2.4 |
| | 3.3 |
| | 6 |
| | 6.6 |
| | 13 |
| | 21.6/12 |
| | 24.7/14 |
| | 17.9/17 |
| | 22/21 |
| | 28.4/27 |
| | 36/35 |
| | 40/38 |
| | 52/50 |
| | 61/58 |
| | 69/66 |
| | 85/81 |
| | 85/81 |
| AC-3 | 400/380V |
| | 1.4 |
| | 1.9 |
| | 3.5 |
| | 4 |
| | 7.5 |
| | 12.6/8 |
| | 25/4.9 |
| | 30/9.5 |
| | 39/9.6 |
| | 49/6.9 |
| | 63/60 |
| | 69/66 |
| | 90/96 |
| | 105/100 |
| | 119/114 |
| | 147/140 |
| Umur Listrik (juta kali) | AC-3 | 1.2 |
| | 1.0 |
| | 1.0 |
| | 1.0 |
| AC-4 | 0.15 |
| | 0.15 |
| | 0.12 |
| | 0.10 |
| | 0.05 |
| Umur Mekanik (puluh ribu kali) | | 1000 |
