NM5NEDC series DC molded case circuit breaker

Product category:: Molded case circuit breaker
Product code:: P-241
Model:: NM5NEDC

Function & Use (Application Scenarios)

Power distribution appliances and plastic case circuit breaker products are mainly suitable for Chint NM5NEDC series DC plastic case circuit breakers, which are suitable for circuits with rated voltage DC1500V and below and rated current 800A to 1600A. As making, breaking and carrying rated current

Surprise on inquiry

Product highlights

Reliable overload protection
Short circuit protection capability
Strong breaking ability
Adaptation to new energy scenarios
Engineering application adaptation

Model

NM5NEDC

Request a Quote Chat on WhatsApp

Main Product Parameters

ClassificationswitchgearSecondary classificationMolded case circuit breaker

parametersRated working voltage: DC750/1000/1500; rated working current: 800A~1600A; rated limit breaking capacity: 25kA/36kA; rated operating breaking capacity: full series Ics=100%IcuAdvantages/core features01 Excellent performance; the rated operating voltage can reach up to DC1500V, meeting high-voltage DC power consumption scenarios; 02 Long life; the mechanical life of the product can reach 15,000 times, greatly reducing later operation and maintenance replacement costs; 03 Safe and reliable; the product is suitable for use in -40~+75℃ environment, and still operates reliably in various harsh environments

Product details

Function and use

Chint NM5NEDC series DC plastic case circuit breakers are suitable for circuits with rated voltage DC1500V and below and rated current 800A to 1600A. As a means of making, breaking and carrying rated current, it can reliably protect lines and electrical equipment when they are overloaded or short-circuited. The products can be widely used in DC power distribution application scenarios in the new energy industry.

Detailed description

Parameters:
Rated working voltage: DC750/1000/1500
Rated working current: 800A~1600A
Rated ultimate breaking capacity: 25kA/36kA
Rated operating breaking capacity: full series Ics=100%Icu

Advantages/core functions:
01 Excellent performance
The rated operating voltage can reach up to DC1500V, meeting high-voltage DC power consumption scenarios.
02 Long lifespan
The mechanical life of the product can reach 15,000 times, which greatly reduces the cost of later operation, maintenance and replacement.
03 Safe and reliable
The product is suitable for use in -40~+75℃ environment and can still operate reliably in various harsh environments.
