Function and Usage
The HDLRT0 series blade-type fuse is suitable for AC 45Hz~62Hz, rated voltage up to 400V, rated current up to 1000A, and rated breaking capacity up to 50kA in distribution circuits for overload protection and short-circuit protection.
Detail Parameters
| Parameter Category | Parameter Item | Parameter Value |
|---|
| 4 Main Parameters and Technical Performance | Model | HDLRT0-100 |
| Domestic and Foreign Equivalent Models | RT0-100 |
| Rated Voltage (V) | AC 380V |
| Rated Current (A) | Base: 100, Fuse Element: 30, 40, 50, 60, 80, 100 |
| Rated Breaking Capacity I1(kA) | 50 |
| Model | HDLRT0-200 |
| Domestic and Foreign Equivalent Models | RT0-200 |
| Rated Current (A) | Base: 200, Fuse Element: 80, 100, 120, 150, 200 |
| Rated Breaking Capacity I1(kA) | 50 |
| Model | HDLRT0-400 |
| Domestic and Foreign Equivalent Models | RT0-400 |
| Rated Current (A) | Base: 400, Fuse Element: 150, 200, 250, 300, 350, 400 |
| Rated Breaking Capacity I1(kA) | 50 |
| Model | HDLRT0-600 |
| Domestic and Foreign Equivalent Models | RT0-600 |
| Rated Current (A) | Base: 600, Fuse Element: 350, 400, 450, 500, 550, 600 |
| Rated Breaking Capacity I1(kA) | 50 |
| Model | HDLRT0-1000 |
| Domestic and Foreign Equivalent Models | RT0-1000 |
| Rated Voltage (V) | AC 400V |
| Rated Current (A) | Base: 1000, Fuse Element: 800, 1000 |
| Rated Breaking Capacity I1(kA) | 50 |
