RT36N Series Blade-Type Fuse Holder

RT36N Series Blade-Type Fuse Holder

Product category:
fuse
Product code:
P-650
Model:
RT36N

Function & Use (Application Scenarios)

Power electrical appliances, fuse products are mainly applicable to a new type of fuse base designed for the communications industry, compatible with RT36 series fuses, suitable for engineering support, installation and maintenance, and long-term stable operation, meeting the on-site application needs of electrical systems.

Surprise on inquiry

Product highlights

  • Smart Communication Support
  • Reliable isolation protection
  • Engineering Application Compatibility
  • Stable and reliable operation
  • Easy system integration

Model

RT36N
Request a QuoteChat on WhatsApp

Main Product Parameters

CategoryIsolating Switch / Load SwitchSecondary categoryCircuit breaker

Product details

Function and Application

RT36N series blade-type fuse base is a new type of fuse base designed for the communications industry, which is compatible with RT36 series fuses

Details Parameters

Parameter CategoryParameter ItemParameter Value
RT36-0 Fuse with RT36N-0 BaseRated Current (A)4, 6, 10, 16, 20, 25, 32, 35, 40, 50, 63, 80, 100, 125, 160
Rated Voltage (V)AC500/AC690/DC250, AC500/AC690/DC250, AC500/AC690/DC250, AC500/AC690/DC250, AC500/AC690/DC250, AC500/AC690/DC250, AC500/AC690/DC250, AC500/AC690/DC250, AC500/AC690/DC250, AC500/AC690/DC250, AC500/AC690/DC250, AC500/AC690/DC250, AC500/AC690/DC250, AC500/AC690/DC250, AC500/AC690/DC250
Breaking Capacity (kA)120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100
RT36-1 Fuse with RT36N-1 BaseRated Current (A)80, 100, 125, 160, 200, 224, 250
Rated Voltage (V)AC500/AC690/DC440, AC500/AC690/DC440, AC500/AC690/DC440, AC500/AC690/DC440, AC500/AC690/DC440, AC500/AC690/DC440, AC500/AC690/DC440
Breaking Capacity (kA)120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100
RT36-2 Fuse with RT36N-2 BaseRated Current (A)125, 160, 200, 224, 250, 300, 315, 355, 400
Rated Voltage (V)AC500/AC690/DC440, AC500/AC690/DC440, AC500/AC690/DC440, AC500/AC690/DC440, AC500/AC690/DC440, AC500/AC690/DC440, AC500/AC690/DC440, AC500/AC690/DC440, AC500/AC690/DC440
Breaking Capacity (kA)120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100
RT36-3 Fuse with RT36N-3 BaseRated Current (A)315, 355, 400, 425, 500, 630
Rated Voltage (V)AC500/AC690/DC440, AC500/AC690/DC440, AC500/AC690/DC440, AC500/AC690/DC440, AC500/AC690/DC440, AC500/AC690/DC440
Breaking Capacity (kA)120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100, 120/50/100
RT36-4 Fuse with RT36N-4 BaseRated Current (A)800, 1000, 1250
Rated Voltage (V)AC500, AC500, AC500
Breaking Capacity (kA)120, 120, 120
