NTK1 Thermostat

Product category:: Axial Fans and Temperature-control Accessories
Product code:: P-731
Model:: NTK1

Function & Use (Application Scenarios)

Electrical accessories and other products, axial fans and temperature control accessories products are mainly used for connecting heaters, when the temperature reaches the set value to break the circuit, used for monitoring filter fans, when the temperature exceeds the set value to close the circuit output signal

Surprise on inquiry

Product highlights

Engineering Application Compatibility
Stable and reliable operation
Easy system integration

Model

NTK1

Request a Quote Chat on WhatsApp

Main Product Parameters

CategoryOther (Tools / Labor Protection / Machining Equipment)Secondary CategoryAxial Fan and Temperature Control Accessories

Product details

Function and Purpose

NTK1 thermostat is used to connect to a heater, and when the temperature reaches the set value, it disconnects the circuit, and is used to monitor the filter fan, and when the temperature exceeds the set value, it closes the circuit to output a signal.

Detailed Parameters

Parameter Category	Parameter Item	Parameter Value
Performance	Mechanical Life	>100000 times
	Contact Status	Single Pole NO; Single Pole NC; Double Pole NO+NC
	Set Temperature Ts	0℃~60℃; -10℃~50℃; 20℃~80℃
	On Temperature	Ts±7℃
	Off Temperature	Single Pole NO: (Ts-6℃)±11℃ Single Pole NC: (Ts+6℃)±11℃ Double Pole NO+NC: NO Contact: (Ts-6℃)±11℃; NC Contact: (Ts+6℃)±11℃
	Contact Capacity	10A @250VAC; 15A@120VAC; 30WDC @ 24VDC~72VDC
	External Terminal Wiring Capability	Solid Core Copper Wire: 0.5 mm²~ 2.5mm² Multi-strand Soft Copper Wire (after crimping): 0.5 mm²~1.5mm²
	Tightening Torque	0.5N·m
