Low voltage complete switchgear · Product code P-286
Product category:
Box type transformer
Product code:
P-286
Model:
BlokSeT3,GCK,GCS,GGD
Function & Use
This series of products adopts advanced modular design, supports flexible combination, can easily build diversified solutions, and perfectly adapts to new energy and smart grid application scenarios. Intelligent monitoring and protection systems can be integrated to achieve efficient, energy-saving, safe and reliable operation.
Category nameMedium and low voltage complete sets of switchgearClassificationMedium voltage complete sets of switchgear Low voltage complete sets of switchgear Box type substation
Product featuresFlexible and diverse: the drawer unit can have up to 36 circuits. The drawer circuit can reach a maximum of 800A; good interchangeability: drawer units with the same specifications and different circuits can be easily interchanged; the three-station mechanical interlocking can effectively prevent electrical failures caused by misoperation; safe and reliable: the complete separation scheme (1b~4b) ensures safe operation; The new drawer unit interlocking mechanism realizes three-station mechanical interlocking, which can effectively prevent electrical failures caused by misoperation; size flexibility: flexible and rich cabinet sizes to optimize on-site space; solution: a full range of low-voltage switch solutions to meet the diverse needs of customersTechnical parametersRated insulation voltage: 690V, 800V, 1000V, 1200V; rated working voltage: 380V, 400V, 690V, 800V, 1140V; main bus rated current: 10~7400A; protection level: IP30/IP40/IP42; isolation form: 1b/2b/3b/4b; application altitude: 0~5600M; cabinet size W*D*H: (600/700/800/900/1000)*(600/800/1000)*(1900/2000/2200); Conventional solutions: incoming cabinet, metering cabinet, capacitor cabinet, APF, bus tie cabinet, feeder cabinet, frequency conversion soft start cabinet
Series product nameBlokSeT3, GCK, GCS, GGD, MDmax, MNS, SIVACON 8PT, power moduleBrandJST
Product details
Functional use: This series of products adopts advanced modular design, supports flexible combination, can easily build diversified solutions, and perfectly adapts to new energy and smart grid application scenarios. Intelligent monitoring and protection systems can be integrated to achieve efficient, energy-saving, safe and reliable operation. The products have obtained international authoritative certifications, including EU CE certification and US UL certification, and have Schneider authorized low-voltage cabinet BlokSeT, ABB authorized low-voltage cabinet MDrmax, and Siemens authorized low-voltage cabinet SIVACON 8PT.
Detailed description: Product features:
Flexible and diverse: the drawer unit can have up to 36 circuits. The drawer circuit can reach a maximum of 800A;
Good interchangeability: drawer units with the same specifications and different circuits can be easily interchanged;
Three-station mechanical interlocking can effectively prevent electrical failures caused by misoperation;
Safe and reliable: The complete separation scheme (1b~4b) ensures safe operation; the new drawer unit interlocking mechanism realizes three-station mechanical interlocking, which can effectively prevent electrical failures caused by misoperation;
Flexible size: flexible and rich cabinet sizes to optimize on-site space;
Solution: A full range of low-voltage switch solutions to meet the diverse needs of customers.
Technical parameters:
Rated insulation voltage: 690V, 800V, 1000V, 1200V
Rated working voltage: 380V, 400V, 690V, 800V, 1140V
Main bus rated current: 10~7400A
Protection level: IP30/IP40/IP42
Isolation form: 1b/2b/3b/4b
Application altitude: 0~5600M
Cabinet size W*D*H: (600/700/800/900/1000)*(600/800/1000)*(1900/2000/2200)
Conventional solutions: incoming cabinet, metering cabinet, capacitor cabinet, APF, bus tie cabinet, feeder cabinet, frequency conversion soft start cabinet
Series product names: BlokSeT3, GCK, GCS, GGD, MDmax, MNS, SIVACON 8PT, power module
